The premium semi-automatic parking system with 3 parking levels
The TrendVario 6300 creates more parking spaces in a small area.
The entrance to the TrendVario 6300 is at ground level. Unlike the other models, the system accommodates three vehicles one above the other, and the parking spaces are moved vertically and horizontally: down into the pit or up to the third parking level. The requested parking space is moved into position. This means that they accommodate more cars within the same floor area.
For maximum operating safety, the access level is secured from the entire system by gates. This also protects the vehicles from theft and vandalism. The semi-automatic parking system offers up to 29 parking spaces in total.
You can also enhance your TrendVario 6300 with our premium accessorires.
Find your individual solutionProduct Finder
Specification*
- For independent parking
- 10 grids behind each other – up to 29 parking spaces are possible
- Building height: 128.0″ to 181.2″ in 2“ increments
- Pit depth: 68.9“ to 94.5“ in 2“ increments
- Vehicle dimensions: height 59.1“ to 84.7“, length 196.9“ to 208.7“
- Usable platform width: 90.6“ to 106.3“
- Platform load: 4,400 lbs per parking space, optionally 5,720 lbs or max. 6,600 lbs
- Horizontal access to all parking levels
- Platform coating: StandardGrip, optional AluLongLife or EasyWalk
- Operation via SmartChip, SmartPortable or SmartApp
- Electronic components are UL compliant
- Seismic reports upon request available
* Assignment according to product data sheet
Field of application
- In residential and commercial buildings in large cities
- For additional parking spaces in office buildings or residential and commercial buildings
- To increase capacity in underground car parks or parking garages, e.g. of hotels
- More parking spaces for car dealerships, car rental companies or vintage car collections
- Ideal in the case of constructions abutting property lines
Specification gates
- Standard gates: vertical gates, electrically
- Electrically sliding gates as an option
- Remote control as an option
- Gate frame made from extruded aluminium profiles with two vertical centre stay bars for the vertical gate and one vertical centre stay bar for the sliding gate
- Standard gating material: perforated aluminium plate
- Optional for sliding gates:
- Around 50 individual variations are possible in different materials and colours
- Glass (laminated safety glass), wood (Nordic spruce), aluminium, steel and many other options available.
- Interchangable panels and segments
Perforated aluminium plate
Type:
- Thickness 1,5 mm, RV 5/8 E6/EV1, anodized, layer thickness approx. 20 μm
- Ventilation cross-section of the panelling approx. 30%
Perforated aluminium plate
Type:
- Thickness 2 mm, RV 5/8 E6/EV1, anodized, layer thickness approx. 20 μm
- Ventilation cross-section of the panelling approx. 40%
Beaded steel plate
Type:
- Thickness 1 mm, hot-dip, layer thickness approx. 20 μm
- Additional powder coating
- Layer thickness approx. 25 μm on the outside and approx. 12 μm on the inside
- Many RAL colours available
Steel wire grating
Type:
- Mesh size 12×12 mm
- Thickness 2 mm, galvanized, layer thickness approx. 20 μm
- Ventilation cross-section of the panelling approx. 70%
Wooden panelling, Nordic spruce
Type
- Nordic spruce, grade A
- Vertical tongue and groove boards
Preimpregnated (colourless)
Plain aluminium sheet
Type:
- Thickness 2 mm, E6/EV1, anodized, layer thickness approx. 20 μm
Laminated safety glass
Type:
- LSG consisting of ESG 8/4 mm
Further visualizations of the TrendVario 6300
The different product variants of the TrendVario 6300
